Steam-air forging hammer KRAMATORSK MA2147 5 ton

# HM-KR-028
  • Condition
  • Good Working.

  • Technical Specifications
  •  -Nominal weight of dropping parts, kg 5000
    -Actual mass of dropping parts without the
    -Upper tool, kg 5080
    -Effective kinetic energy of dropping parts at
    -Full consecutive blows kJ 125
    -Number of strikes per min: 50
    -Max course of the hammer block, mm 1300
    -Min height of tools without shanks, mm 400
    -Distance between columns, mm 800
    -Length of the hammer block (at direction,
    -Perpendicular to hammer front), mm 950
    -Length of the die holder (at direction,
    -Perpendicular to hammer front), mm 1180
    -Steam pressure before an admission to
    -The cylinder, atm 7.. 9
    -Nominal weight of the upper tool, kg 500
    -Max weight of the upper tool, kg 1500
    -Max admitted temperature of steam, degr. C 200
    -Overall dimensions, mm:3700 x 2000 x 8770
    -Weight, kg: 140364

Steam-air forging hammer KRAMATORSK MA2147 5 ton
